ADL
| Dimension |
|
|
|
|
|
|
|
|
|
|
Unit: |
mm |
| Model |
A |
B |
C |
D |
E |
F |
G |
H |
I |
J |
K |
L |
| 65ADL51.1 |
627 |
651 |
152 |
275 |
133 |
32 |
25.4 |
125 |
70 |
15 |
17.5 |
65 |
| 80ADL51.5 |
634 |
670 |
152 |
275 |
133 |
32 |
25.4 |
125 |
70 |
15 |
17.5 |
65 |
| 80ADL52.5 |
693 |
675 |
152 |
275 |
133 |
32 |
25.4 |
125 |
70 |
15 |
17.5 |
65 |
| 80ADL53.7 |
723 |
701 |
152 |
275 |
133 |
32 |
25.4 |
125 |
70 |
15 |
17.5 |
65 |
| 100ADL55.5 |
874 |
750 |
230 |
366 |
202 |
32 |
25.4 |
125 |
70 |
15 |
17.5 |
65 |
| 100ADL57.5 |
874 |
750 |
230 |
366 |
202 |
32 |
25.4 |
125 |
70 |
15 |
17.5 |
65 |
Download PDF :
Share this product:
Product Description
| Model No. |
Outupt |
Outlet |
Silid |
Max |
LPM Flow @ Head |
Max |
Dimention |
Weight |
| HP |
kW |
mm |
inch |
Dia(mm) |
Flow(LPM) |
3M |
6M |
9M |
12M |
15M |
Head(M) |
L x W x H(mm) |
kg |
| 65ADL51.5 |
2 |
1.5 |
65 |
2.5″ |
40 |
850 |
750 |
570 |
370 |
180 |
– |
15 |
503x349x577 |
58 |
| 80ADL51.5 |
2 |
1.5 |
80 |
3″ |
50 |
1000 |
850 |
620 |
300 |
– |
– |
12 |
537x368x599 |
62 |
| 80ADL52.2 |
2 |
2.2 |
80 |
3″ |
50 |
1200 |
1100 |
850 |
550 |
250 |
– |
15 |
542x373x658 |
75 |
| 80ADL53.7 |
2 |
3.7 |
80 |
3″ |
50 |
1700 |
1620 |
1450 |
1210 |
920 |
570 |
18 |
567x399x688 |
92 |
| 100ADL55.5 |
7.5 |
5.5 |
100 |
4″ |
75 |
2800 |
2700 |
2250 |
1700 |
1200 |
700 |
19 |
653x400x824 |
121 |
| 100ADL57.5 |
10 |
7.5 |
100 |
4″ |
75 |
3200 |
3150 |
2200 |
1600 |
1600 |
1000 |
21 |
653x400x824 |
125 |
